| Weight Capacity |
136 kg (300 lbs.) |
| Maximum Speed |
Up to 6.44 km/h (4.0 mph)
(non-elevated position)
Up to 5.6 km/h (3.5 mph)
(elevated position) |
| Ground Clearance |
6.15 cm (2.42″) at footplate
2.54 cm (1.00″) at motor bracket |
High-Back
Seat to Floor |
Range 58.42 cm – 83.57 cm (23″ – 32.9″) |
| Turning Radius |
57.15 cm (22.5″) |
| Overall Size |
Length: 110 cm (43.2”) with foot
rigging;
98 cm (38.6”) w/out foot rigging
Width: 59.5 cm (23.4”) at the wheels
64.8 cm (25.5”) with armrests |
| Drive Controller |
PG VR2 |
| Drive Wheels |
25.4 cm (10”) flat free |
| Caster Wheels |
15.24 cm (6”) flat free |
| Suspension |
Active-Trac® w/
Mid-Wheel 6® Technology |
| Range |
Up to 29.64 km (18.4 miles) |
Component
Weights |
Base: 111 kg (245 lbs.)
Batteries: 40 Ah-14.6 kg (32.2 lbs.) |
| Drivetrain |
Two motor, Mid-Wheel-6 drive |
| Brakes |
“Intelligent Braking”
(electronic regenerative,
disc park brakes) |
| Batteries |
(2) 12V, 40 Ah |
| Battery Charger |
3.5 amp, off-board |
| Max. Allowable Incline |
6° |
| Max. Angle Capacity |
6° |
Maximum Obstacle
Climbing Ability |
Lowered Position: 5.6 cm (2.2”)
Elevated Position: 4.6 cm (1.8”) |
